(b) Mode 1 (High Resolution (J2))
ASCII, UVW, Continuous, Speed of Sound On, Sonic Temp On, [Analogue inputs On], PRT On
<STX><ID>,±UUU.UUU,±VVV.VVV,±WWW.WWW,U,±CCC.CC,±TTT.TT,
SS,[±1.1111,±2.2222,±3.3333,±4.4444],±PP.PPC,<ETX>CC<CR><LF>
Where:
<STX> - Start of string character (ASCII value 2)
<ID> - Anemometer Identification (A-Z)
±UUU.UUU - ‘U’ axis velocity 0.001ms
-1
units
±VVV.VVV - ‘V’ axis velocity 0.001ms
-1
units
±WWW.WWW ‘W’ axis velocity 0.001ms
-1
units
U - Units (M=m/s)
±CCC.CC - Speed of Sound in 0.01ms
-1
units
±TTT.TT - Sonic Temperature in Degrees C.
SS - Status data (Codes 00 to 0B)
±1.1111 - Analogue input 1 in volts
±2.2222 - Analogue input 2 in volts
±3.3333 - Analogue input 3 in volts
±4.4444 - Analogue input 4 in volts
±PP.PPC - PRT temperature in degrees C, e.g. +23.13deg C output as +23.13C in the string.
<ETX> - End of string character (ASCII value 3)
CC - Checksum of all Characters between <STX> and <ETX> (HEX byte)
<CR><LF> - Carriage Return and Line Feed
7.2. Mode 2 – ASCII, Polar, Continuous (Default Output Parameters in red)
(a) Mode 2 (Normal Resolution Shown J1)
ASCII, Polar+W, Continuous, Speed of Sound On, Sonic Temp On, [Analogue inputs On], PRT On
Format for software configuring is:-
<STX><ID>,DDD,MMM.MM,±WWW.WW,U,±CCC.CC,TTT.TT,SS,[±1.1111,±2.2222,±3.3333±4.4444],
PP.PPC,<ETX>CC<CR><LF>
Where:
<STX> - Start of string character (ASCII value 2)
<ID> - Anemometer Identification (A-Z)
DDD - Direction in degrees
MMM.MM - Wind Magnitude
±WWW.WW - ‘W’ axis velocity 0.01ms
-1
units
U - Units (M=m/s, N=knots, P=mph, K=kph)
±CCC.CC - Speed of Sound in 0.01ms
-1
units
±TTT.TT - Sonic Temperature in Degrees C.
SS - Status data (Codes 00 to 0B)
±1.1111 - Analogue input 1 in volts
±2.2222 - Analogue input 2 in volts
±3.3333 - Analogue input 3 in volts
±4.4444 - Analogue input 4 in volts
±PP.PPC - PRT temperature in degrees C, e.g. +23.13deg C output as +23.13C in the string.
<ETX> - End of string character (ASCII value 3)
CC - Checksum of all Characters between <STX> and <ETX> (HEX byte)
<CR><LF> - Carriage Return and Line Feed
Parameters are as described in Para 7.1 except that :-
<STX>
Q,333,001.09,
-
001.70,M
,+344.22,+021.01,
00
,+2.4181,+2.4187,+2.4162,+2.4175,
-
50.00C,<ETX>
64
Node
address
Direction
in
Degrees
Wind
Magnitude
W axis
velocity
and
polarity
Units
Speed of
Sound
Sonic
Temp
.
Status
A. I/P
1
A. I/P
2
A. I/P
3
A.I/P
4
PRT
Check
Sum
