Settings and how to change them are explained in the following section.
Changing settings
To change a setting, refer to the sections below, and enter the command of the new setting required, followed by
ENTER . If successful, the new setting will be sent back as a message by the WindMaster.
For example, to change the message format to UVW, Continuous, enter M 1 ENTER
The WindMaster will reply M1. When the unit is returned to the Measurement mode, it will be in UVW, Continuous
format.
Note : The factory-set (default) settings are shown in bold in the following sections.
Command List
COMMAND
USER
A
SOS/Sonic Temp Output
B
Baud rate
C
Analogue angle wrapping
D
Diagnostic
/ Config info
E
Set Physical Comms
F
Signal Processing
G
Averaging Settings
H
Power on message
I
Disable/Enable analogue input
J
High/Low Resolution
K
Minimum Direction Velocity
L
Message Terminator
M
Message Format
N
Set Unit ID
O
Set ASCII fo
rmat
P
Set output rate
Q
MEASUREMENT MODE
R
Not used
S
Analogue output range
T
Analogue output type & Config
U
Select Units
V
PRT output ON/OFF
W
Not Used
X
Axis Alignment
Y
Not Used
Z
Not used
*
INTERACTIVE MODE
Where the command is a single parameter command the notation is Dx, for example if the parameter x = 2 then in
interactive mode the user would type “D2”.
Where the Command is dual parameter e.g. Fx y, then x selects the parameter and y turns it on or off (Fx<space>y).
Typing just the command letter will cause the current settings to be output.
Warning: Certain combinations of output rate, baud rate and message type may be unsupported.
