WindMaster and WindMaster Pro 1561-PS-0001. Issue 11 February 2017
________________________________________________________________________________________________________________________
41
7.4. Mode 4 –ASCII, Polar, Polled.
Mode 4 (Normal Resolution Shown)
ASCII, Polar+W, Polled, Speed of Sound On ,Sonic Temp On, [Analogue inputs On], PRT On
<STX><ID>,DDD,MMM.MM,WWW.WW,U,CCC.CC,TTT.TT,SS,[±1.1111,±2.2222,
±3.3333±4.4444],PP.PPC,<ETX>CC<CR><LF>
Where:
<STX> - Start of string character (ASCII value 2)
<ID> - Anemometer Identification (A-Z)
DDD - Direction in degrees
MMM.MM - Wind Magnitude
±WWW.WW - ‘W’ axis velocity 0.01ms
-1
units
U - Units (M=m/s, N=knots, P=mph, K=kph)
±CCC.CC - Speed of Sound in 0.01ms
-1
units
±TTT.TT - Sonic Temperature in Degrees C.
SS - Status data (Codes 00 to 0B)
±1.1111 - Analogue input 1 in volts
±2.2222 - Analogue input 2 in volts
±3.3333 - Analogue input 3 in volts
±4.4444 - Analogue input 4 in volts
±PP.PPC - PRT temperature in degrees C, e.g. +23.13deg C output as +23.13C in the string.
<ETX> - End of string character (ASCII value 3)
CC - Checksum of all Characters between <STX> and <ETX> (HEX byte)
<CR><LF> - Carriage Return and Line Feed
See also Polled Notes above.
7.5. Mode 7 –Binary, Polar, Short
<B1><B1>STATUS,DIR,MAG,W,SOS,CHECKSUM
<B1> -
<B1> -
STATUS - Status data (Codes 00 to 10)
DIR Wind Direction
MAG Wind Speed
W W axis velocity
SOS Speed of Sound in 0.01ms
CHECKSUM
Notes:-
Data is 2 byte signed two’s complement (except unsigned for SOS; 1 byte for checksum).
Velocities are normal resolution (0.01m/s).
Outputs that are disabled are padded with zero to give fixed size records.
A Gill Binary to ASCII Converter is available to download from http://gillinstruments.com/main/software.html
7.6. Mode 8 –Binary, UVW, Short
<B2><B2>STATUS,U,V,W,SOS,CHECKSUM
<B2> -
<B2> -
STATUS - Status data (Codes 00 to 0B)
U U axis velocity
V V axis velocity
W W axis velocity
SOS Speed of Sound in 0.01ms
-1
CHECKSUM
