GMI PS200 series Handbook

vi
AUTO BUMP / CAL STATION - HANDBOOK
CONNECT CALIBRATION GAS & POWER SUPPLY
2-1
2.1 CONNECT CALIBRATION GAS 2-1
2.1.1 Compare Gas Cylinder Label with Software
Conguration 2-2
2.1.2 Connect Gas Cylinder to Auto Bump / Cal
Station 2-4
2.1.3 Connect Air / Exhaust Tubing to Auto Bump /
Cal Station (if required) 2-6
2.2 CONNECT POWER SUPPLY 2-8
VIEW / RE-CONFIGURE SOFTWARE 3-1
3.1 VIEW / EDIT SOFTWARE CONFIGURATION 3-1
3.1.1 Quick Bump Test 3-5
3.1.2 Full Bump Test (Factory Default) 3-6
3.1.3 Calibration 3-10
3.1.4 Generate Settings File 3-14
3.2 TRANSFER UPDATED ‘PS200 SETTINGS’
SOFTWARE to AUTO BUMP / CAL STATION 3-15
INSTALL INSTRUMENT IN STATION & PERFORM
BUMP / CALIBRATION 4-1
4.1 INSTALL INSTRUMENT in AUTO BUMP / CAL
STATION 4-1
4.2 PERFORM BUMP / CALIBRATION 4-6

GMI PS200 series Specifications

General

Display	LCD
Alarm Type	Audible, visual, and vibration alarms
Resolution	Depends on the gas being detected
Accuracy	Varies depending on the gas and sensor. Consult the specific sensor datasheet.
Operating Temperature	-20°C to +50°C
Power Supply	Rechargeable Li-ion battery
Pump Type	Built-in sample pump
