GÖLZ KB 300 User Manual

KB300 / KB350 with FS560
Translation of the original operating instruction and spare parts list
- 9-
5006892-01
BA-E
®
1. Technical data and accessory
1.1 Technical data of the machine
1.1.1 KB300 / KB350
Type KB 300 KB 350
Stroke 450 - 17.7 450 - 17.7 mm - in.
Feed Manual Manual
Angle drilling up to 45° up to 45°
Weight 21 - 46.3 24 - 53 kg - lbs.
Weight with motor 41 - 90.4 44 - 97 kg - lbs.
Length 440 - 17.3 550 - 21.6 mm - in.
Breadth 340 - 13.4 410 - 16.1 mm - in.
Height 800 - 31.5 800 - 31.5 mm - in.
Drilling range
Ø 110 - Ø 290
Ø 4.4 - Ø 11.4
Ø 110 - Ø 354
Ø 4.4 - Ø 13.9
mm - in.
1.1.2 Motor STIHL
®
Type FS560
Driving mechanism STIHL
®
- single cylinder - two-stroke-engine
Capacity 57,1 cm³
Cylinder bore 47 - 1.85 mm - in.
Piston stroke 32,9 - 1.3 mm - in.
Power 2,8 (3,8) kW (PS)
Max. operating speed of the spindle 100 / 300 / 600 RPM
Weight with drilling gear 20 - 44.1 kg - lbs.
Continuous sound level Lpeq 101 dB(A) according to ISO 22868
Sound power level Lweq 114 dB(A) according to ISO 22868
Vibration measurement a 3,3 m/s² according to ISO 22867
Ignition system (with electronic speed limit)
Principle Electronically controlled magneto
Spark plug (interference-suppressed) NGK BPMR7A
Electrode gap 0,5 - 0,02 mm - in.
Fuel system
Carburettor
Non position sensitive diaphragm carburettor with
integrated fuel pump
Air filter Paper
Fuel tank capacity 0,99 (990) L (cm³)
