15
860-7200-18 DTU DTB Service & Maintenance Manual
Center of Gravity
MACHINE OVERVIEW
Power Supply
Connection
Remote Panel
(Mobile or Anchored)
End of Travel Sensor
LED Light Strips (on both masts)
Rotary Handle (on both sides of machine)
Sensing Edge or Front Area Scanner (optional)
Control Panel
Rear Area Scanner (optional)
Conveyor
(additional conveyor
sections are optional)
Emergency Stop (E-Stop Button)
Remote Section
Lockable Casters
Operator Platform
Fan
Pivoting Conveyor
Drive Panel
Middle Conveyor
Battery
Rear Conveyor
(Gravity Skate Wheels
for Destu-it™
or Powered Belt
for Restu-it™)
Remote Panel (Anchored)Remote Panel (Mobile)
Pressure Sensing Safety Mats (two on both sides of machine)
Lifting Points (two on both sides of machine)
To Next Page
