GORBEL Destuff-it DTU - Control Panel

21
860-7200-18 DTU DTB Service & Maintenance Manual
CONTROL PANEL
E-Stop Button
A
CONTROL PANEL (CASE)
CONTROL PANEL (DOOR)
A
Fuses
Terminals
Relays
Safety Relay
PLC (Programmable Logic Controller)
Analog Output Modules
PLC Inputs
PLC Outputs
B
C
D
E
E
F
G
H
I
B
C
D
F
G
NOTE: If your machine has network integration, the Control
Panel will appear dierent. Please see Appendix.
H
I
