BELT CONFIGURATION LAYOUTS
M1220GX24X1KIT - Front Conveyor Belt Repair 24” w x 1” Lg Griptop
M1220GX30X1KIT - Middle and Rear Conveyor Belt Repair 30” w x 1” Lg Griptop
Rod Removal Tool (Part # H010702262):
Do not use a hammer and punch to
remove rods to avoid damage to links.
Do not run conveyors with DAMAGED BELT LINKS!
Damaged links must be replaced right away to
prevent further damage to belt.
