GORBEL Destuff-it DTU - Drive Panel

23
860-7200-18 DTU DTB Service & Maintenance Manual
DRIVE PANEL
E-Stop button
AC Disconnect switch
DC Disconnect switch
A
B
C
DRIVE PANEL (CASE)
DRIVE PANEL (DOOR)
Drive Relays
Drive Motor Fuses
Drive Motor Boards
D
E
H
I
J
K
L
F
G
N
O
P
N N
O P
P
NOTE: If your machine has network integration, the Drive
Panel will appear dierent. Please see Appendix.
Fuses
VFDs (Variable Frequency Drives)
Relays
PMD (Phase Monitor Relay)
Hydraulic Pump Overload Relay
Battery Charger Contactor
Hydraulic Pump Contactor
Main Contactor
Conveyor Motor - 2 & 3 Overload Relays
H
A
B
C
D
E E
G
H
F
I
J
K
L
