860-7200-18 DTU DTB Service & Maintenance Manual
LUBRICATION POINTS
LOCATION: Pivoting Conveyor (Modular Belt) GREASE
ITEM PART INTERVAL FITTING TYPE QTY
Bearings for Head and
Tail Shafts
Every 2,000 hours Straight
NLGI 2 grease such as
Castrol MP
0�04 oz
Idler Bearings (2) Every 2,000 hours Straight
NLGI 2 grease such as
Castrol MP
0�04 oz
Front Conveyor Drive
Bearings (6)
Every 2,000 hours Straight
NLGI 2 grease such as
Castrol MP
0�09 oz
NOTES
If possible relubricate while the bearing is rotating� Add full amount until grease purge is seen from the seals� If this is
not an option for safety reasons, follow this alternate procedure: Stop rotating equipment� Add half the grease� Start the
bearing and run for a few minutes� Stop the bearing and add the second half of grease�
1.4
1.4
1.4
1.5
1.5
1.6
1.6
3.7
