36
860-7200-18 DTU DTB Service & Maintenance Manual
Head shaft bearing (left, front corner of front pivoting conveyor)
Tail shaft bearing (left, rear corner of front pivoting conveyor)
Tail shaft bearing (right, rear corner of front pivoting conveyor)
Head shaft bearing (right, front corner of front pivoting conveyor)
Idler bearing (left, rear corner of front pivoting conveyor)
Idler bearing (right, rear corner of front pivoting conveyor)
1.4
1.4
1.4
1.4
1.5
1.5
