5.2. SNMP INTERFACE FOR NTP SERVER CARD
The NTP server card provides its own a SNMP v1 interface for ne monitoring and diagnos-
tic. Its private MIB is described in the le GtNtpServer.mib provided on the CDROM in the
directory English\LEDI Network IN\MIB.
Localization in the MIB:
iso(1).org(3).dod(6).internet(1).private(4).enterprises(1).gorgy(8955).software(1).ntpSrv(3)
5.2.1. Software information MIB for the NTP server outcard
General organization
This branch contains all the information related to the server software itself. Here is the
structure of this branch:
5. SNMP INTERFACE
General information
Information related to the
hardware PPS tracking
algorithm
Information related to the
synchronization network dialog
Information related to the
external synchronization
