2.2. OUTPUT CARDS CONFIGURATION
2.2.1. Introduction
Your LEDI Network IN is provided with up to 4 output cards. Each output card is tightly
synchronized on the NTP time code received from the NTP server. Each card acts as
a kind of translator that receives time from the NTP software and output specic time
code.
Currently, there are 6 kinds of cards:
ASCII+TOP RS232 (‘A’ type card) ►
ASCII+TOP RS485 (‘R’ type card). ►
AFNOR NFS 87500 / IRIGB (‘B’ type card). ►
AFNOR /IRIGB TTL / RS422 (‘T’ type card). ►
ALARM (‘G’ type card). ►
NTP server (‘N’ type card). ►
You can freely use and copy the table Devices conguration in Appendix F – Additional
documents.
2.2.2. Default conguration
When you receive this product from Gorgy Timing, all the output cards are congured to
output UTC time and time is constant all along the year (no Day Saving Time correction).
The display is managed as an output cards and can be congured in the same way..
2.2.3. Change the settings
Open the WEB site of the LEDI Network IN (see part 5). Click on the button.
The current conguration of your product appears at the screen (shown below for a 9257/
A model):
2. FULL SETUP
