Common Parts
The parts listed below are common among all 20, 30,
and 60 liter platens. Parts that vary are found in the
tables on page 60-61.
Varying Parts - 20 Liter (5 Gallon) Platens
The following table indicates which parts (according to reference number) are included with each platen.
Parts designated n/a are not available separately. ‡ See page 59 for wiper assembly kits.
Varying Parts - 30 Liter (8 Gallon) Platens
The following table indicates which parts (according to reference number) are included with each platen.
Parts designated n/a are not available separately. ‡ See page 59 for wiper assembly kits.
Ref. Part Description Qty.
456 121829 O-RING 1
459 555413 NUT, (For SST platens) 12
113504 NUT, keps, hex hd (For CSTL platens) 12
461 257697 HANDLE, bleed, sst 1
463 109482 O-RING; see page 61 1
465 C20350ELBOW, 90°; 1/4 OD x 1/4 npt 1
Ref. Description
Reference Numbers
Qty:257727 257728 257729 257730 257731 25A206
451 BASE 257665 257665 257662 257665 257665 257662
1
452‡
SPACER 276049 276049 276049 257694 257694 276049
1
453‡
WIPER, main 257672 257678 257675 257672 (2) 257678 (2) 25A208
1 (2)
454‡
WIPER, PE support 257681 257681 257681 257681 257681 257681
1
455‡
PLATE, bottom 257668 257668 257671 257668 257668 257671
1
457‡
PLATE, top - clamp retainer 257692 257692 257698 257686 257686 257698
1
460‡
WIPER, support 257689 n/a
1
462‡
SCREW, cap, hex hd 100057 100057 112894 100057 100057 112894
2
464
VALVE, check 122056 122056 501867 122056 122056 501867
1
468‡
TAG, instructions n/a n/a n/a n/a
1
469‡
COVER 15W184 15W184 15W184 15W184
1
470‡
PIN, hairpin, cotter (10 pack) 16U740 16U740 16U740 16U740
2
Ref.
Reference Numbers
Qty:Description 257732 257733 257734 257735 257736
451 BASE 257665 257665 257662 257665 257665
1
452‡
SPACER 194148 194148 194148 257695 257695
1
453‡
WIPER, main 257673 257679 257676 257673 (2) 257679 (2)
1 (2)
454‡
WIPER, PE support 257682 257682 257682 257682 257682
1
455‡
PLATE, bottom n/a n/a n/a n/a n/a
1
457‡
PLATE, top n/a n/a n/a n/a n/a
1
460‡
WIPER, support 257690
1
462‡
SCREW, cap, hex hd 100057 100057 112894 100057 100057
2
464
VALVE, check 122056 122056 501867 122056 122056
1
468‡
TAG, instructions n/a n/a n/a
1
469‡
COVER 15X403 15X403 15X403
1
470‡
PIN, hairpin, cotter (10 pack) 16U740 16U740 16U740
2
