Thisequipmentstayspressurizeduntilpressure
ismanuallyrelieved.Tohelppreventserious
injuryfrompressurized󰘱uid,suchasskininjection,
splashing󰘱uidandmovingparts,followthe
PressureReliefProcedurewhenyoustopspraying
andbeforecleaning,checking,orservicingthe
equipment.
1.TurnOFF(O)theESOn/Offswitch.
2.Engagethetriggerlock.
3.Turnofftheairbleedvalvestothe󰘱uidsource
andtothegun.
4.Disengagethetriggerlock.
5.Triggerthegunintoagroundedmetalwaste
containertorelievethe󰘱uidpressure.
6.Engagethetriggerlock.
7.Openthepumpdrainvalve,havingawaste
containerreadytocatchthedrainage.Leave
thepumpdrainvalveopenuntilyouareready
tosprayagain.
8.Ifthespraytiporhoseiscompletelycloggedor
pressureisnotfullyrelieved,slowlyloosenthe
hoseendcoupling.Nowclearthespraytipor
hose.
