Graco Pro Xp H60T10 - Controls, Indicators, and Components

GunOverview
Controls, Controls,
Controls,
Indicators, Indicators,
Indicators,
and and
and
Components Components
Components
Theelectrostaticgunincludesthefollowingcontrols,indicators,andcomponents(seeFig.1).Forinformation
onSmartguns,alsoseeSmartGuns,page9.
Figure1GunOverview
Item Item
Item
Description Description
Description
Purpose Purpose
Purpose
A
AirSwivelInlet1/4npsm(m)left-handthread,forGracogroundedairsupplyhose.
BFluidInlet
1/4npsm(m),for󰘱uidsupplyhose.
C
TurbineAirExhaust
Barbed󰘰tting,forsuppliedexhausttube.
D
AirCap/TipGuardand
SprayTip
SeeSprayTipSelectionChart,page61,foravailablesizes.
EElectrode
Supplieselectrostaticchargetothe󰘱uid.
FFanAirAdjustmentValve
Adjustsfansizeandshape.Canbeusedtodecreasepatternwidth.
G
AtomizingAirAdjustment
Valve
Adjustsatomizingair󰘱ow.
H
TriggerSafetyLockLockstriggertopreventgunfromspraying.
J
ESOn-OffValveTurnselectrostaticsON(I)orOFF(O).
K
ESIndicator(standard
gunonly;forSmart
gunindicator,see
OperatingMode,page9)
LitwhenESisON(I).Colorindicatesalternatorfrequency.Seethe
LEDindicatortableintheGunSetupProcedure,page21.
LInlineFluidFilter
Provides󰘰nal󰘰ltrationof󰘱uid.Locatedinside󰘱uidtube󰘰tting.
83A2495K
