Graco Pro Xp H60T10 - Page 40

Repair
Air Air
Air
Cap, Cap,
Cap,
Spray Spray
Spray
Tip, Tip,
Tip,
and and
and
Fluid Fluid
Fluid
Seat Seat
Seat
Housing Housing
Housing
Replacement Replacement
Replacement
1.SeePreparetheGunforService,page39.
2.Removetheretainerring(22)andaircap/tip
guardassembly(25).
Figure20RemoveAirCap
3.Disassembletheaircapassembly.Checkthe
conditionoftheu-cup(22a),o-ring(25b),andtip
gasket(27a).Replaceanydamagedparts.
Figure21DisassembleAirCapAssembly
Figure22TipGasket
4.Toreplacetheelectrode(25a),see
ElectrodeReplacement,page41.
Theconductivering(9)isaconductivemetal
contactring,notasealingo-ring.Toreduce
theriskof󰘰re,explosion,orelectricshock:
•Donotremovetheconductiveringexcept
toreplaceit.
•Neveroperatethegunwithouttheconductive
ringinplace.
•Donotreplacetheconductiveringwith
anythingbutagenuineGracopart.
5.Triggerthegunandremovethe󰘱uidseathousing
(24),usingthemulti-tool(61).
Figure23ReplaceFluidSeatHousing
403A2495K
