DEMAND TYPES:
These demands are displayed at the top left on the display. The demand will only show if there is a
trigger calling for the demand.
DEFAULT SETTINGS:
ZONE SETUP - Default Settings
Type
Configuration
Displayed
on
Controller
Trigger Type
Supply
Target
/
Supply
Max
Supply
Min
Outdoor
Design
WWSD
Fan-coil Heating
Outdoor-reset
FC_W
Thermostat
150°F
120°F
-20°F
80°F
Instantaneous DHW Heating
Setpoint
DHW
Flow Sensor
(Internal)
125°F
DHW Recirculation
Setpoint
RECIRC
Controller
Logic
125°F
Fan-coil Blower - Default Settings
Heating
Fan Speed
[W]
Circ Fan
Speed [G]
Cool 1 Fan
Speed [Y1]
Cool 2 Fan
Speed [Y2]
700 RPM
400 RPM
700 RPM
1100 RPM
Displayed on
Controller
Description of Demand
DHW Domestic Hot Water
FC_W Fan-coil Heating (W)
RECIRC Domestic Hot Water Re-circ
ZN4 Secondary Domestic Heating
FC_Y1 Fan-coil Cooling Stage 1 (Y1) (FULL)
FC_Y2 Fan-coil Cooling Stage 2 (Y2)
FC_G Fan-coil Air Circulation (G)
Demand Types
