Gradient syncFURNACE mOD-200 - Burner Setup; Setup Menu Commissioning

syncFURNACE OD Instruction & Installation Manual – Rev 09 Pg. 51 of 81
COMMISSIONING:
Burner Setup
- Used to force burner to operate at MAXIMUM, MINIMUM or IGNITION burner input rate to
perform gas valve calibration and/or combustion analysis of burner system.
SETUP MENU
1) ZONE SETUP
2) BURNER SETUP
3) COMMISSIONING
4) STATISTICS
5) REMOTE MONITORING
Burner Setup
Combustion Blower Override
- This setting allows users to force burner to operate at maximum, minimum & ignition
burner input rates.
NOTE: Once calibration or combustion analysis is completed ensure this setting is
returned to the OFF setting.
(OFF, MAX, MIN, IGN) Default: OFF
BURNER SETUP
1) BLOWER ORIDE OFF
Commissioning
- Used to manually turn pumps on / off and exercise internal valve’s to remove air from
system prior to ignition of burner system. Also allows user to turn combustion blower on /
off to purge venting prior to burner system ignition.
NOTE: Commissioning will commence for a 10 minute period – after which the setting will
reset back to its default (OFF) state.
SETUP MENU
1) ZONE SETUP
2) BURNER SETUP
3) COMMISSIONING
4) STATISTICS
5) REMOTE MONITORING
Commissioning
Pumps Exercise
- This setting allows users to turn all pumps ON constantly for 10 minutes or use the
AUTO setting that turns all pumps ON then OFF every second for 5 straight seconds and
then pauses for 30 seconds and repeats.
(OFF, AUTO, ON) Default: OFF
Combustion Blower Exercise
- This setting allows users to turn on the combustion blower to purge the venting
system.
(OFF, ON) Default: OFF
3 Way Valve Exercise
- This setting allows users to adjust the position of the 3-way valve.
(OFF, MID, ON) Default: OFF
COMMISSIONING
2) COMB BLOWER
3) STEPPER
OFF
OFF
1) PUMPS OFF
COMMISSIONING
1) PUMPS
3) STEPPER
ON
OFF
2) COMB BLOWER
OFF
COMMISSIONING
1) PUMPS
2) COMB BLOWER
AUTO
OFF
3) STEPPER OFF
