Defrost water
The cabinet creates defrost water, that is directed out into a
re-evaporation tray at the back of the cabinet.
BioCompact II 610
Defrost water is led through a tube in the insulation to a
re-evaporation tray at the back of the cabinet.
BioCompact II 210, 310, 210/210, 310/210, and 410
Defrost water is led through a tube in the insulation to a
re-evaporation tray in the compressor room in the cabinet.
Below the re-evaporation trays for a BioCompact II 410 and
BioCompact II 610 are shown.
It is recommended that the re-evaporation tray is
checked regularly for foreign objects and cleaned
accordingly. This shall only be done while the
cabinet is turned o.
Be careful not to damage the defrost water tube
and heating element (located in the tray) when
cleaning.
