DP750/DP720 Administration Guide
Version 1.0.11.4
Phonebook XML
Server Path
Indicates server path to download XML phonebook file. This field could be IP
address or URL, with up to 256 characters.
Phonebook
Download Interval
Sets interval to send XML phonebook download requests (in minutes). If set to 0,
automatic download is disabled. Valid range is 5 to 720. Default is 5 minutes.
Upload: Uploads manually global XML phonebook file to the base station.
Delete: Clears global XML phonebook file in the base station.
Downloads global XML phonebook from the base station in .xml format.
Global Phonebook LDAP Settings
Selects type of global phonebook to use.
If set to XML, DP750 will use the configuration in Global Phonebook XML Settings
page. If set to LDAP, DP750 will use configuration in Global Phonebook LDAP
Settings page.
Chooses LDAP or LDAPS (LDAP over TLS) protocol. Default is LDAP.
Configures IP address or domain name of the LDAP server.
Determines LDAP server port. Default is 389.
Indicates the location in the directory where the search is requested to begin.
Example:
dc=grandstream, dc=com
ou=Boston, dc=grandstream, dc=com
Binds "Username" for querying LDAP servers. Some LDAP servers allow
anonymous binds in which case the setting can be left blank.
Binds "Password" for querying LDAP servers. The field can be left blank if the LDAP
server allows anonymous binds.
LDAP filter to limit which contacts are fetched from the server. LDAP statement to
limit which contacts are fetched from the server. Statement must be in parenthesis.
Selects LDAP protocol version to send bind requests. Default is Version 3.
Defines first name attributes of each record to be returned in the LDAP search
result.
This field allows users to configure multiple space separated name attributes.
Example:
gn
