DP750/DP720 Administration Guide
Version 1.0.11.4
Base: Specifies Base version.
Prog: Specifies Prog version. This is the main firmware release number,
which is always used for identifying the software system of the DP750.
Locale: Specifies Locale version.
Recovery: Specifies Recovery version.
Handset: Specifies Handset firmware version.
Indicates system uptime since last reboot.
Shows actual time and date according to your configuration.
Reveals status of VoIP applications.
Profiles Page Definitions
Table 10: Profiles Page Definitions
Activates or deactivates SIP profile.
Determines the name of the profile, this profile name can also be used in handset
config provisioning for validation. By default, the values are profile 1 – profile 4.
Configures SIP server IP address or domain name provided by VoIP service
provider. This is the primary SIP server used to send/receive SIP messages from/to
DP750.
Specifies failover SIP server IP address or domain name provided by VoIP service
provider. This server will be used if the primary SIP server becomes unavailable.
Prefer Primary SIP
Server
Prefers primary SIP server. The profile will register to primary Server if registration
with Failover server expires. Default is No.
Specifies IP address or domain name of outbound proxy, media gateway or session
border controller. Used by DP750 for firewall or NAT penetration in different network
environments. If symmetric NAT is detected, STUN will not work and only outbound
proxy can correct the problem.
Defines the voice mail portal access number to allow users accessing their voice
messages. Maximum allowed length is 30 characters.
Defines Diff-Serv values for SIP and RTP. Defaults are:
SIP Diff-Serv: 24 ; RTP Diff-Serv: 46
