DP750/DP720 Administration Guide
Version 1.0.11.4
Line Options
Account
Displays list of configured accounts’ names, from Account 1 to Account 10.
SIP User ID
Displays list of SIP user id registered.
DND
Shows DND (Do Not Disturb) feature status (per SIP account).
Forward
Indicates destination to which all incoming calls will be forwarded (per SIP account).
Busy Forward
Indicates destination to which incoming calls will be forwarded when the line is busy
(per SIP account).
Delayed Forward
Indicates destination to which incoming calls will be forwarded if the call is not
answered within a specified period of time or number of rings (per SIP account).
Network Status
MAC Address
Shows Device ID in hexadecimal format. This is needed by network administrators
for troubleshooting. The MAC address will be used for provisioning and can be
found on the label on original box and on the label located on the bottom panel of
the device.
IP Address Mode
Indicates used IP address mode: DHCP, Static IP or PPPoE.
IP Address
Displays assigned IP address. Example: 192.168.5.110
Subnet Mask
Displays assigned subnet mask. Example: 255.255.255.0
Gateway
Displays assigned default gateway. Example: 192.168.5.1
PPPoE Link Up
Indicates PPPoE connection status.
DNS Server 1
Shows assigned DNS server address 1. Example: 8.8.8.8
DNS Server 2
Shows assigned DNS server address 2. Example: 8.8.4.4
NAT Traversal
Indicates type of NAT for each Profile. (Based on STUN protocol.)
System Info
Product Model
Displays product model info. Default is DP750.
Part Number
Shows product part number. Example: 9610003814A (last 2 digits show HW
version, in this example 14A for HW version 1.4A)
Software Version
 Firmware Status: Displays the status of the firmware loaded.
 Boot: Specifies Boot version.
 Core: Specifies Core version.
