so that they can share data and sync files. Press MENU button button and select
"Advanced". Then tap on "Wi-FI Direct", the Available devices will be displaied.
- Wi-Fi Configuration
o Saved Networks: this is to show all the Wi-Fi Networks that are registered on the phone.
o Network notification: If enabled, the phone will show notification on the top status bar
indicating an open network is available. By default it's enabled.
o MAC address: This shows the MAC address of the WiFi.
o IP address: This shows the IP address of the phone from Wi-Fi network.
General Network Settings
• LLDP
Turn on/off LLDP on the GXV3370. If turned on, the phone will be able to discover the LAN polices as
set up in the switch side to obtain network settings such as VLAN tag, Layer 2 QoS 802.1p priority and
Layer 3 QoS in a plug-and-play manner.
• LLDP TX Interval
Specifies the time interval, in seconds, between successive LLDP-MED transmission cycles
• Layer 3 SIP QoS
This field defines the layer 3 QoS parameter for SIP packets.
This is the value used for IP Precedence, Diff-Serv or MPLS. The Default value is 26.
• Layer 3 Audio QoS
This field defines the layer 3 QoS parameter for audio packets. This is the value used for IP Precedence,
Diff-Serv or MPLS. The Default value is 46.
• Layer 3 Video QoS
This field defines the layer 3 QoS parameter for video packets. This is the value used for IP Precedence,
Diff-Serv or MPLS. The Default value is 34.
• Second Layer Qos 802.1Q/VLAN tag (Ethernet)
This field contains the value used for layer 2 VLAN tagging for the Ethernet network.
The Default value is 0.
• Second Layer QoS 802.1p/Priority Value (Ethernet)
This assigns the priority value of the Layer 2 QoS packets on the Ethernet Network.
The Default value is 0.
• Layer 2 QoS 802.1p priority(Wi-Fi)
This assigns the priority value of the Layer 2 QoS packets on the Wi-Fi Network. Default value is 0.
