P a g e | 33
• Firmware:
o Upgrade Mode: This field allows the user to choose the firmware upgrade method: TFTP, HTTP
or HTTPS.
o HTTP/HTTPS username: The user name for the HTTP/HTTPS server if set up on the server.
o HTTP/HTTPS password: The password for the HTTP/HTTPS server if set up on the server.
o Firmware Server Path: This defines the server path for the firmware server. It can be different
from the configuration server for provisioning.
• Config:
o Upgrade mode: This field allows the user to choose the provisioning method: TFTP, HTTP or
HTTPS.
o HTTP/HTTPS username: The user name for the HTTP/HTTPS server if set up on the server.
o HTTP/HTTPS password: The password for the HTTP/HTTPS server if set up on the server.
o Config Server Path: This defines the server path for the provisioning server. It can be different
from the firmware server.
Syslog
• Syslog level: Select the level of logging for syslog. The default setting is "None". There are 4 levels:
DEBUG, INFO, WARNING and ERROR.
• System log protocol: Select the protocol of syslog (UDP or SSL/TLS).
• Syslog server address: The URL/IP address for the syslog server. If the GXV3370 has network
connection, the phone will send the syslog packets to this server address.
• System log keyword filtering: Only send the syslog with keyword, multiple keywords are
separated by comma. Example: set the filter keyword to “SIP” to filter SIP log.
System Security
• Disable Web Login: This disables web GUI access.
• Developer Mode. To enable/disable developer mode.
• Data Wiping. To clear and erase all the data and configuration.
• Factory Reset. Restore default settings.
About
Account Status
This page displays all available accounts on the phone with respective status (Configured/Not Configured
and Registered/Unregistered).
