Grandstream Networks GXV33 Series Administration Guide

GXV3370 Administration Guide
Version 1.0.1.12
P a g e | 80
• UTF-32
• Big5
• Big5-HKSCS
• Shift-JIS
• ISO8859-1
• ISO8859-15
• Windows-1251
• EUC-KR
Download Server
Configures the server URL to download the phonebook file.
The phone system will send a request to the server to download the
phonebook file with filename phonebook.xml.
HTTP/HTTPS User Name
Configures user name for HTTP/HTTPS server to download the
phonebook file.
HTTP/HTTPS Password
Specifies password for HTTP/HTTPS server to download phonebook file.
Automatic Download
Interval
Determines how the phone system to send the request to the server to
download the phonebook file. It can be selected from the dropdown list:
• None
• 2 Hour
• 4 Hour
• 6 Hour
• 8 Hour
• 12 Hour
Download Now
Starts downloading the XML phonebook to the phone immediately.
System Application/LDAP Book
Connection Mode
Selects which protocol will be used for LDAP searching, LDAP or LDAPS.
Server Address
Configures the URI of the LDAP (Lightweight Directory Access Protocol)
server.
Port
Configures the LDAP server port. The default LDAP port number is 389.
Base DN
Determines the LDAP search base. This is the location in the directory
where the search is requested to begin.
Example:
dc=grandstream, dc=com
ou=Boston, dc=grandstream, dc=com
User Name
Configures the bind "Username" for querying LDAP servers. Some LDAP
servers allow anonymous binds in which case the setting can be left blank.
Password
Specifies the bind "Password" for querying LDAP servers. The field can be
left blank if the LDAP server allows anonymous binds.
