Grandstream Networks GXV33 Series Administration Guide

GXV3370 Administration Guide
Version 1.0.1.12
P a g e | 57
Phone Settings/Ring Tone
Auto Config CPT by
Region
Configures whether to choose Call Progress Tone automatically by region.
If set to "Yes", the phone will configure CPT (Call Progress Tone)
according to different regions automatically. If set to "No", you can manual
configure CPT parameters. The default setting is "No".
Call Progress Tones:
• Dial Tone
• Second Dial Tone
• Ring Back Tone
• Busy Tone
• Reorder Tone
• Confirmation Tone
• Call-Waiting Tone
Configures tone frequencies according to user preference. By default, the
tones are set to North American frequencies. Frequencies should be
configured with known values to avoid uncomfortable high pitch sounds.
Syntax: f1=val,f2=val [,c=on1/off1[-on2/off2[-on3/off3]]];
(Frequencies are in Hz and cadence on and off are in 10ms)
ON is the period of ringing ("On time" in "ms") while OFF is the period of
silence. In order to set a continuous ring, OFF should be zero. Otherwise
it will ring ON ms and a pause of OFF ms and then repeats the pattern.
Please refer to the document below to determine your local call progress
tones: http://www.itu.int/ITU-T/inr/forms/files/tones-0203.pdf
Call-Waiting Tone Gain
Adjusts the call waiting tone volume. Users can select "Low", "Medium" or
"High". The default setting is "Low".
Default Ring Cadence
Defines the ring cadence for the phone. The default setting is:
c=2000/4000.
Phone Settings/Video Settings
Video Frame Rate
Configures video frame rate for SIP video call from “5 frames/second”, “15
frames/second”, “25 frames/second”, “30 frames/second” and “Variable
frames rate”. The default setting is 15 frames/second. The video frame rate
is adjustable based on network conditions. Increasing the frame rate will
significantly increase the amount of data transmitted, therefore consuming
more bandwidth. The video quality will be affected due to packet loss if
extra bandwidth is not allocated.
Video Display Mode
Configures the video display mode to "Original proportion", "Equal
proportional cutting" or "Proportional add black edge". If set to "Original
proportion", the phone displays video in its original proportion. If the video
display proportion is different from the one of the phone, the phone will
stretch or compress video to display it; If set to "Equal proportional cutting",
the phone will cut video to meet its own display proportion; If set to
"Proportional add black edge", the phone will display video in its original
proportion. If it still exists spare space, the phone will add black edge on it.
The default setting is "Equal proportional cutting".
Enable Frame Skipping
in Video Decoder
Enables the phone system for frame skipping in video decoder. If it is
enabled, the video decoder will skip the P frame and start decoding from
