GXV3370 Administration Guide
Version 1.0.1.12
The OpenVPN® Client key (*.key) required by the OpenVPN® server for
authentication purposes. Press "Upload" to upload the corresponding file
to the device.
The cipher method of OpenVPN®, must be the same cipher method used
by the OpenVPN® server.
OpenVPN® authentication username (optional).
OpenVPN® authentication username (optional).
System Settings/Advanced Network Settings
Advanced Network Settings
Defines the secondary DNS IP address if the static IP is used.
Second Alternate DNS
Server
Configures the secondary alternate DNS IP address to failover during both
the default DNS server and alternate DNS server’s outage.
Enables the LLDP (Link Layer Discovery Protocol) feature on the phone
system. If it is set to “Yes”, the phone system will broadcast LLDP PDU to
advertise its identity and capabilities and receive same from a physical
adjacent layer 2 peer.
The default setting is "Yes".
Configures the interval the phone sends LLLD-MED packet.
The default setting is 30s.
Configures whether to enable CDP to receive and/or transmit information
from/to CDP-enabled devices.
The default setting is "No".
Defines the Layer 3 packet’s QoS parameter for SIP messages in decimal
pattern. This value is used for IP Precedence, Diff-Serv or MPLS.
The default setting is 48 which is equivalent to the DSCP name constant
CS6.
Defines the Layer 3 packet’s QoS parameter for RTP messages in decimal
pattern. This value is used for IP Precedence, Diff-Serv or MPLS.
The default setting is 48 which is equivalent to the DSCP name constant
CS6.
Defines the Layer 3 packet’s QoS parameters for H.264 messages in
decimal pattern. This value is used for IP Precedence, Diff-Serv or MPLS.
The default setting is 48 which is equivalent to the DSCP name constant
CS6.
Sets the user-agent for phonebook and screen saver.
Sets the user-agent for SIP.
