GXV3370 Administration Guide
Version 1.0.1.12
Specifies the rules for the incoming calls. If the incoming caller ID or Alert Info
matches the number, pattern or Alert Info text rules, the phone will play the selected
distinctive ringtone. The rule policy:
• Specific caller ID number. For example, 8321123;
• A defined pattern with certain length using x and + to specify, where x could be
any digit from 0 to 9. Samples:
xx+ : at least 2-digit number;
xx : only 2-digit number;
[345]xx: 3-digit number with the leading digit of 3, 4 or 5;
[6-9]xx: 3-digit number with the leading digit from 6 to 9.
• Alert Info text
Users could configure the matching rule as certain text (e.g., priority) and select
the custom ring tone mapped to it. The custom ring tone will be used if the phone
receives SIP INVITE with Alert-Info header in the following format:
Alert-Info: <http://127.0.0.1>; info=priority
Selects the distinctive ring tone if the incoming caller ID matched the specified Match
Incoming Caller ID rule. If so, the phone will play the selected ringtone.
Upload Local
MOH Audio File
Loads the MOH (Music on Hold) file to the phone. Click on “Browse” button to upload
the music file from local PC. The MOH audio file has to be in .wav or .mp3 format.
Note: Please be patient while the audio file is being uploaded. It could take more
than 3 minutes to finish the uploading especially the file size is large. The button will
show as “Processing” during the uploading. Once done, it will show as “Browse”
again. Click on “Save” on the bottom of the web page and “Apply” on the top of the
web page to save the change.
Plays local MOH file if the call is being hold by the phone. Default setting is “No”.
If yes, c=0.0.0.0 will be used in INVITE SDP for hold.
It is used to set to categorize accounts in server mode groups, the accounts in the
same group will be combined as one and the account widget will display the Caller
ID in the account with lowest ID. The phone can answer any incoming calls to each
account in groups.
If user makes an outbound call, the phone system will use the lowest ID account by
default. If the account fails or SIP INVITE message is timeout, the phone system will
failover to the next account in the group with higher account ID.
If all the accounts are not available in the group, the phone system will traverse all
the accounts in the group and notify the end users the session is failed.
Configures phone’s settings to meet different vendors’ server requirements.
Users can choose from Standard, CBCOM, RNK, China Mobile, ZTE IMS, Mobotix,
ZTE NGN, or Huawei IMS depending on the server type.
