Create a Job with Smart Input:
As mentioned, there are several parameters that are required when using the Smart Input to set up a job:
Lead Trim – distance from lead edge to first cut
Card Length – length of the finished card (2” if creating a business card job)
Gutter length – distance between two images
To access the Smart Trim feature, Press the Mode Key 4. When Smart Input is
displayed, enter the value for the distance between the lead edge and the first
cut. For the Graphic Whizard business cards, this value is 0.3. Press enter to
advance to the next screen.
Next, enter the length of the finished job. For the standard North American
business card, the length is 2”. Press Enter. Key in the gutter length, the
distance between two images. For the GW business card template, this
distance is 0.2”.
If the job has creases, enter the position of the crease on the finished job. For
example, the GW 6 ticket job has the following PT 331SCC parameters:
Lead Trim: 1.5”
Card Length: 8”
Cut Gutter: 2.5”
Cross Perf (Crease): 2”
At the crease 1 prompt, 2.00 would be entered. It is not necessary to enter the next cross perf as the SCC will auto
program the crease based on the job parameters. If no creases are required, press enter to advance to the next
screen.
Note: A maximum of four creases can be programmed using Smart Input. If required, more creases can be
programmed after completing Smart Input.
When all the information has been entered, the display will return to the Ready screen.
