1-10
Introduction
(8) Pull out the sheet support pipes, and attach the sheet to them. Pass the sheet under the
center bar, and fasten the ends to the support pipes using the press-studs.
Sheet
Pass under the center bar
Sheet support pipe
Press-stud
(9) Attach the stoppers (L/R) to the stock shaft and then attach the shaft to the top of the stand.
Stock shaft
Stopper
Collar
