-98-
G0513 Series Bandsaws (Mfd. Since 07/18)
BUY PARTS ONLINE AT GRIZZLY.COM !
Scan QR code to visit our Parts Store.
G0513X2, G0513X2B, G0513X2BF &
G0513X2F Guides & Trunnions Parts List
REF PART # DESCRIPTION REF PART # DESCRIPTION
98 P0513X2098 CAP SCREW M10-1.5 X 35 151-7 P0513X2151-7 ECCENTRIC SHAFT
103 P0513X2103 LOCK WASHER 10MM 151-8 P0513X2151-8 EXT RETAINING RING 15MM
104 P0513X2104 FLAT WASHER 10MM 151-9 P0513X2151-9 BALL BEARING 6202ZZ
136 P0513X2136 CAP SCREW M5-.8 X 10 151-10 P0513X2151-10 HANDLE BUSHING
137 P0513X2137 FLAT WASHER 5MM 151-11 P0513X2151-11 CAP SCREW M6-1 X 35
138 P0513X2138 UPPER BLADE GUARD 155 P0513X2155 CAST IRON TRUNNION ASSEMBLY
139V2 P0513X2139V2 CAP SCREW M10-1.5 X 35 155-1 P0513X2155-1 FLAT WASHER 8MM
140 P0513X2140 STEP SCREW M4-.7 X 5 155-2 P0513X2155-2 LOCK NUT M8-1.25
141 P0513X2141 FIBER WASHER 5MM 155-3 P0513X2155-3 PHLP HD SCR M4-.7 x 6
142 P0513X2142 SLIDING PLATE 155-4 P0513X2155-4 GEAR PLATE
145 P0513X2145 GUIDE POST ASSEMBLY 155-5 P0513X2155-5 FLAT HD SCR M4-.7 X 6
145-1 P0513X2145-1 SET SCREW M5-.8 X 5 155-6 P0513X2155-6 CARRIAGE BOLT M8-1.25 X 85
145-2 P0513X2145-2 CAP SCREW M6-1 X 16 155-7 P0513X2155-7 CAST IRON TRUNNION
145-3 P0513X2145-3 PHLP HD SCR M4-.7 X 10 155-8 P0513X2155-8 CARRIAGE BOLT M8-1.25 X 80
145-4 P0513X2145-4 HEX NUT M4-.7 155-9 P0513X2155-9 LOCK HANDLE M8-1.25
145-5 P0513X2145-5 RACK 155-10 P0513X2155-10 TABLE TILT SCALE
145-6 P0513X2145-6 GUIDE POST 155-11 P0513X2155-11 FLAT WASHER 8MM
145-7 P0513X2145-7 LOCK COLLAR 155-12 P0513X2155-12 HEX BOLT M8-1.25 X 25
145-8 P0513X2145-8 THREADED BUSHING V2.06.09 155-13 P0513X2155-13 LOCK HANDLE M8-1.25
145-9 P0513X2145-9 LOCK WASHER 8MM 155-14 P0513X2155-14 FLAT WASHER 4MM
145-10 P0513X2145-10 THREADED GUIDE BRACKET 14MM V2.06.09 155-15 P0513X2155-15 POINTER
145-11 P0513X2145-11 WORM CYLINDER 155-16 P0513X2155-16 LOCK WASHER 8MM
145-12 P0513X2145-12 FIXED PLATE 155-17 P0513X2155-17 ADJUSTMENT KNOB BOLT M6-1
145-13 P0513X2145-13 PINION GEAR 15T 155-18 P0513X2155-18 HEX NUT M6-1
145-14 P0513X2145-14 PINION GEAR STEP BOLT 155-19 P0513X2155-19 L-BRACKET
145-15 P0513X2145-15 BRACKET COVER 155-20V2 P0513X2155-20V2 FLAT HD SCR M5-.8 X 8
145-16 P0513X2145-16 CAP SCREW M8-1.25 X 16 155-21 P0513X2155-21 CAP SCREW M6-1 X 16
145-17 P0513X2145-17 FLAT HD SCR M4-.7 X 8 155-22 P0513X2155-22 CAP SCREW M6-1 X 50
145-18 P0513X2145-18 BUSHING 155-23 P0513X2155-23 TRUNNION SUPPORT BRACKET
146 P0513X2146 GUIDE POST HANDWHEEL 155-24 P0513X2155-24 TRUNNION GEAR
147 P0513X2147 CAP SCREW M6-1 X 20 155-25 P0513X2155-25 BUTTON HD CAP SCR M10-1.5 X 30
150 P0513X2150 UPPER BLADE GUIDE ASSEMBLY 155-26 P0513X2155-26 RIGHT GUARD
150-1 P0513X2150-1 CAP SCREW M6-1 X 16 155-27 P0513X2155-27 BALL BEARING 6000ZZ
150-2 P0513X2150-2 UPPER GUIDE SUPPORT BLOCK 155-28 P0513X2155-28 FLAT WASHER 10MM
150-3 P0513X2150-3 SET SCREW M6-1 X 10 155-29 P0513X2155-29 LEFT GUARD
150-4 P0513X2150-4 ADJUSTMENT BAR 155-30 P0513X2155-30 ADJUSTMENT ROD
150-5 P0513X2150-5 UPPER BLADE GUIDE SUPPORT 155-31 P0513X2155-31 LOCK WASHER 8MM
150-6 P0513X2150-6 ECCENTRIC SHAFT 155-32 P0513X2155-32 CAP SCREW M5-.8 X 6
150-7 P0513X2150-7 EXT RETAINING RING 15MM 155-33 P0513X2155-33 LOCK WASHER 10MM
150-8 P0513X2150-8 BALL BEARING 6202ZZ 352 P0513X2352 FLAT WASHER 8MM
150-9 P0513X2150-9 HANDLE BUSHING 353 P0513X2353 LOCK WASHER 8MM
150-10 P0513X2150-10 CAP SCREW M6-1 X 35 354 P0513X2354 BUTTON HD CAP SCR M8-1.25 X 20
150-11 P0513X2150-11 UPPER SPACING SHAFT 355 P0513X2355 HEX WRENCH 5MM
151 P0513X2151 LOWER BLADE GUIDE ASSEMBLY 356 P0513X2356 HEX WRENCH 8MM
151-5 P0513X2151-5 LOWER BLADE GUIDE SUPPORT 357 P0513X2357 WRENCH 10 X 13 OPEN-END
151-6 P0513X2151-6 CAP SCREW M6-1 X 16
