G0513 Series Bandsaws (Mfd. Since 07/18)
Figure 10. Other bandsaw components.
D
E
F
G
H
G0513X2
Shipping Inventory (Figures 9–10) Qty
A. Bandsaw (not shown) ................................. 1
B. Table ........................................................... 1
C. Miter Gauge ................................................ 1
D. Rear Rail .................................................... 1
E. Resaw Fence ............................................ 1
F. Front Rail .................................................... 1
G. Fence Assembly ......................................... 1
H. Guide Post Handwheel............................... 1
Hardware & Tools (Not Shown) Qty
• Flat Washers 8mm (Table, Fence, Rail) ..... 5
• Lock Washers 8mm (Table, Rail) ............... 4
• Hex Bolts M8-1.25 x 25 (Table) .................. 4
• Hex Bolt M8-1.25 x 90 (Positive Stop) ........ 1
• Hex Nuts M8-1.25 (Positive Stop, Fence)... 2
• Cap Screws M6-1 x 16 (Rear Rail) ............. 2
• Hex Bolt M6-1 x 20 (Front Rail) .................. 2
• Lock Washers 6mm (Rail) .......................... 2
• Flat Washers 6mm (Rail) ............................ 2
• Table Pin..................................................... 1
• Table Insert ................................................. 1
• Locking Handle M8-1.25 x 44 (Fence) ....... 1
• Fence Handle M8-1.25 x 22 (Fence) .......... 1
• Moving Plate (Fence).................................. 1
• Hex Wrench 5mm, 8mm....................1 Each
• Open-End Wrench 10 x 13mm ................... 1
Figure 9. Table and miter gauge.
C
B
