Grizzly G0513 User Manual

-74-
G0513 Series Bandsaws (Mfd. Since 07/18)
READ ELECTRICAL SAFETY
ON PAGE 71!
G0513X2BF Wiring Diagram
Hot
Hot
Ground
220V 6-15 Plug
(As Recommended)
220
VAC
G
RESET
96
98
1/2 3/4
L1/1 L3/5 NO13L2/3
5/6
8
10
12
NC15
T1/2
T3/6
T2/4
NC16
NO14
95
22
21
14
13
22
21
14
13
22
21
14
13
Power Supply Junction Box
Magnetic Switch Assembly
Control Panel
(Viewed from Behind)
Foot Brake
Switch
R
S
R
S
A
Contactor
SDE MA-18
Power
ON
OFF
U
V
Motor
E
E
E
E
E
Set at
8.7A
Magnetic
Brake YZG
U
V
Rectifier PU-23-2
OL Relay
SDE RA-20
Ground
Ground
Ground
Run Capacitor
45MFD 450VAC
Ground
