Grizzly G0513 User Manual

-82-
G0513 Series Bandsaws (Mfd. Since 07/18)
BUY PARTS ONLINE AT GRIZZLY.COM !
Scan QR code to visit our Parts Store.
G0513 & G0513ANV Upper Blade Guides &
Miter Gauge Parts List
REF PART # DESCRIPTION REF PART # DESCRIPTION
6 P0513006 SET SCREW M5-.8 X 5 161V2 P0513161V2 THREADED BUSHING V2.06.09
134 P0513134 GUIDE ADJUSTMENT SHAFT 162 P0513162 CAP SCREW M8-1.25 X 20
136 P0513136 CAP SCREW M8-1.25 X 80 163 P0513163 LOCK WASHER 8MM
137 P0513137 FLAT WASHER 8MM 164V2 P0513164V2 THREADED GUIDE BRACKET 14MM V2.06.09
138 P0513138 UPPER BLADE GUARD (G0513/G0513P) 165 P0513165 WORM CYLINDER
138 P0513ANV138 UPPER BLADE GUARD (G0513ANV) 166 P0513166 FIXED PLATE
138-1 P0513138-1 BLADE GUARD SCALE 167 P0513167 PINION GEAR 15T
140 P0513140 STEP SCREW M4-.7 X 5 168 P0513168 PINION GEAR STEP BOLT
141 P0513141 FIBER WASHER 5MM 169 P0513169 BRACKET COVER
142 P0513142 SLIDING PLATE (G0513/G0513P) 170 P0513170 CAP SCREW M8-1.25 X 16
142 P0513ANV142 SLIDING PLATE (G0513ANV) 171 P0513171 PHLP HD SCR M4-.7 X 8
143 P0513143 EXT RETAINING RING 15MM 172 P0513172 SET SCREW M6-1 X 16
144 P0513144 BALL BEARING 6202ZZ 173 P0513173 MITER GAUGE ASSY
145 P0513145 UPPER BLADE GUIDE SUPPORT 173-1 P0513173-1 GUIDE BAR
146 P0513146 BLADE GUIDE 173-2 P0513173-2 T-SLOT WASHER 5MM
147 P0513147 THUMB SCREW M6-1 X 16 173-3 P0513173-3 INDICATOR
149 P0513149 CAP SCREW M6-1 X 15 173-4 P0513173-4 NYLON WASHER 1/4"
150 P0513150 ADJUSTMENT SHAFT 173-5 P0513173-5 MITER GAUGE HANDLE 1/4"-20
151 P0513151 UPPER SPACING SLEEVE 173-6 P0513173-6 MITER GAUGE BODY
153 P0513153 UPPER GUIDE SUPPORT BLOCK 173-7 P0513173-7 INDEXING PIN
154 P0513154 PHLP HD SCR M4-.7 X 10 173-8 P0513173-8 PHLP HD SCR M6-1 X 6
155 P0513155 HEX NUT M4-.7 173-9 P0513173-9 FLANGE SCREW M5-.8 X 8
156 P0513156 RACK 174V2 P0513174V2 HEX NUT M16-1.5 THIN
157A P0513157A GUIDE POST ASSEMBLY 192 P0513192 HEX WRENCH 5MM
157 P0513157 GUIDE POST 193 P0513193 HEX WRENCH 8MM
158 P0513158 ELEVATION HANDWHEEL 194 P0513194 WRENCH 10 X 13MM OPEN-END
159 P0513159 HEX BOLT M6-1 X 20 196 P0513196 STEEL BALL 5MM
160 P0513160 PINION GEAR STEP BOLT
