Grizzly G0513 User Manual

-86-
G0513 Series Bandsaws (Mfd. Since 07/18)
BUY PARTS ONLINE AT GRIZZLY.COM !
Scan QR code to visit our Parts Store.
G0513X2 Main Parts List
REF PART # DESCRIPTION REF PART # DESCRIPTION
2 P0513X2002 SET SCREW M6-1 X 10 55 P0513X2055 UPPER WHEEL COVER
3 P0513X2003 BUSHING 56 P0513X2056 HEX BOLT M6-1 X 25
4 P0513X2004 LIFTING EYE BOLT M10-1.5 57 P0513X2057 FLAT WASHER 6MM
5 P0513X2005 MACHINE BODY 58 P0513X2058 WHEEL BRUSH
7 P0513X2007 BUSHING 59 P0513X2059 CAP SCREW M6-1 X 25
8 P0513X2008 FLAT WASHER 6MM 60 P0513X2060 STAR KNOB
9 P0513X2009 POWER CORD 14G 3W 72" 61 P0513X2061 LOCK NUT M6-1
10 P0513X2010 HEX NUT M6-1 62 P0513X2062 STRAIN RELIEF 16MM STRAIGHT LT
11 P0513X2011 POINTER 63 P0513X2063 HEIGHT POINTER
12 P0513X2012 STEP SCREW M4-.7 X 5 64 P0513X2064 HEX NUT M8-1.25
13 P0513X2013 HINGE SHAFT 65 P0513X2065 HEX BOLT M8-1.25 X 90
14 P0513X2014 ROLL PIN 5 X 36 66 P0513X2066 STAR KNOB BOLT M10-1.5 X 20
15 P0513X2015 UPPER WHEEL SHAFT HINGE 67 P0513X2067 STAR KNOB BOLT M10-1.5 X 55
16 P0513X2016 UPPER WHEEL SHAFT 68 P0513X2068 THREADED HANDLE M10-1.5
17 P0513X2017 UPPER WHEEL ASSEMBLY 69 P0513X2069 CAM
17-1 P0513X2017-1 BUSHING 70 P0513X2070 PILLOW BLOCK
17-2 P0513X2017-2 BALL BEARING 6204-2RS 71 P0513X2071 HANDLE M12-1.75
17-3 P0513X2017-3 INT RETAINING RING 47MM 72 P0513X2072 LEVER
17-4 P0513X2017-4 UPPER WHEEL 17" 73 P0513X2073 HEX NUT M12-1.75
17-5 P0513X2017-5 URETHANE TIRE 17" 1-PAIR 74 P0513X2074 LEVER HUB
18 P0513X2018 LOWER WHEEL ASSEMBLY 75 P0513X2075 BUTTON HD CAP SCR M8-1.25 X 20
18-1 P0513X2018-1 BUSHING 76 P0513X2076 LOCK WASHER 8MM
18-2 P0513X2018-2 BALL BEARING 6204-2RS 78 P0513X2078 SHAFT COVER
18-3 P0513X2018-3 INT RETAINING RING 47MM 79 P0513X2079 SET SCREW M8-1.25 X 20
18-4 P0513X2018-4 LOWER WHEEL 17" 80 P0513X2080 HEX NUT M8-1.25
18-5 P0513X2018-5 URETHANE TIRE 17" 1-PAIR 81 P0513X2081 LOWER WHEEL SHAFT
21 P0513X2021 WHEEL FLAT WASHER 8MM 82V2 P0513X2082V2 MOTOR 2HP 110V/220V 1-PH V2.01.10
22 P0513X2022 CAP SCREW M8-1.25 X 16 82-1V2 P0513X2082-1V2 MOTOR FAN COVER V2.01.10
23 P0513X2023 SAW BLADE 131.5" X 1/2" 6TPI HOOK 82-2V2 P0513X2082-2V2 MOTOR FAN V2.01.10
24 P0513X2024 LOCK WASHER 8MM 82-3V2 P0513X2082-3V2 S CAPACITOR 300M 250V 1-1/2 X 2-3/8 V2.01.10
25 P0513X2025 CAP SCREW M8-1.25 X 20 82-4V2 P0513X2082-4V2 S CAPACITOR COVER V2.01.10
28 P0513X2028 LOWER WHEEL PULLEY 82-5V2 P0513X2082-5V2 R CAPACITOR 40M 250V 1-3/8 X 2-5/8 V2.01.10
29 P0513X2029 HEX NUT 1-14 82-6V2 P0513X2082-6V2 R CAPACITOR COVER V2.01.10
30 P0513X2030 LOCK WASHER 1" 82-7V2 P0513X2082-7V2 MOTOR JUNCTION BOX V2.01.10
31 P0513X2031 MOTOR CORD 14G 3W 82-8 P0513X2082-8 CONTACT PLATE 5/8
32 P0513X2032 COMPRESSION SPRING 7 X 8 X 90 82-9 P0513X2082-9 CENTRIFUGAL SWITCH 5/8-1725
33 P0513X2033 ROLL PIN 3 X 16 82-10 P0513X2082-10 BALL BEARING 6203ZZ
34 P0513X2034 ALIGNMENT PLATE 82-11 P0513X2082-11 BALL BEARING 6205ZZ
35 P0513X2035 THRUST BEARING 51201 83 P0513X2083 HEX BOLT M10-1.5 X 25
36 P0513X2036 2-BUTTON START/STOP SWITCH 84 P0513X2084 LOCK WASHER 10MM
37 P0513X2037 TENSION HANDWHEEL 85 P0513X2085 MOTOR MOUNT BRACKET
38 P0513X2038 TENSION ADJUSTING ROD 86 P0513X2086 BUTTON HD CAP SCR M8-1.25 X 20
39 P0513X2039 FLANGE SCREW M5-.8 X 10 87 P0513X2087 STRAIN RELIEF PLATE 2-HOLE
40 P0513X2040 EXT TOOTH WASHER 5MM 88 P0513X2088 FLANGE SCREW M5-.8 X 10
41 P0513X2041 HEX NUT M5-.8 89 P0513X2089 PILLOW BLOCK
42 P0513X2042 FLANGE SCREW M5-.8 X 16 90 P0513X2090 KEY 5 X 5 X 35
43 P0513X2043 SWITCH BACK PLATE 91 P0513X2091 HEX BOLT M8-1.25 X 20 LH
44 P0513X2044 CAP SCREW M8-1.25 X 16 92 P0513X2092 MOTOR PULLEY TYPE-A 3.5"
45 P0513X2045 FENDER WASHER 8MM 93 P0513X2093 V-BELT A42
46 P0513X2046 UPPER WHEEL SLIDING BRACKET 94 P0513X2094 CAP SCREW M6-1 X 10
47 P0513X2047 CAP SCREW M8-1.25 X 50 95A P0513X2095A LOWER WHEEL COVER
48 P0513X2048 STEEL BLIND RIVET 3 X 13MM 97 P0513X2097 FENDER WASHER 8MM
49 P0513X2049 CAP SCREW M6-1 X 10 111 P0513X2111 CAP SCREW M6-1 X 20
50 P0513X2050 CLEAR WINDOW 119 P0513X2119 LOCK WASHER 4MM
55A P0513X2055A UPPER WHEEL COVER ASSY
