Grizzly G0513 User Manual

G0513 Series Bandsaws (Mfd. Since 07/18)
-89-
BUY PARTS ONLINE AT GRIZZLY.COM !
Scan QR code to visit our Parts Store.
G0513X2B Main Parts List
REF PART # DESCRIPTION REF PART # DESCRIPTION
2 P0513X2B002 SET SCREW M6-1 X 10 41 P0513X2B041 START BUTTON
3 P0513X2B003 BUSHING 44 P0513X2B044 CAP SCREW M8-1.25 X 16
4 P0513X2B004 LIFTING EYE BOLT M10-1.5 45 P0513X2B045 FENDER WASHER 8MM
5 P0513X2B005 MACHINE BODY 46 P0513X2B046 UPPER WHEEL SLIDING BRACKET
7 P0513X2B007 BUSHING 47 P0513X2B047 CAP SCREW M6-1 X 25
8 P0513X2B008 FLAT WASHER 6MM 48 P0513X2B048 STEEL BLIND RIVET 3 X 13MM
10 P0513X2B010 HEX NUT M6-1 49 P0513X2B049 CAP SCREW M6-1 X 10
11 P0513X2B011 POINTER 50 P0513X2B050 CLEAR WINDOW
12 P0513X2B012 STEP SCREW M4-.7 X 5 51 P0513X2B051 KEY SWITCH
13 P0513X2B013 HINGE SHAFT 55A P0513X2B055A UPPER WHEEL COVER ASSY
14 P0513X2B014 ROLL PIN 5 X 35 55 P0513X2B055 UPPER WHEEL COVER
15 P0513X2B015 UPPER WHEEL SHAFT HINGE 56 P0513X2B056 HEX BOLT M6-1 X 25
16 P0513X2B016 UPPER WHEEL SHAFT 57 P0513X2B057 FLAT WASHER 6MM
17 P0513X2B017 UPPER WHEEL ASSEMBLY 58 P0513X2B058 WHEEL BRUSH
17-1 P0513X2B017-1 BUSHING 59 P0513X2B059 CAP SCREW M6-1 X 25
17-2 P0513X2B017-2 BALL BEARING 6204-2RS 60 P0513X2B060 STAR KNOB
17-3 P0513X2B017-3 INT RETAINING RING 47MM 61 P0513X2B061 LOCK NUT M6-1
17-4 P0513X2B017-4 UPPER WHEEL 17" 62 P0513X2B062 STRAIN RELIEF 16MM STRT LT
17-5 P0513X2B017-5 URETHANE TIRE 17" 1-PAIR 63 P0513X2B063 HEIGHT POINTER
18 P0513X2B018 LOWER WHEEL ASSEMBLY 64 P0513X2B064 HEX NUT M8-1.25
18-1 P0513X2B018-1 BUSHING 65 P0513X2B065 HEX BOLT M8-1.25 X 90
18-2 P0513X2B018-2 BALL BEARING 6204-2RS 66 P0513X2B066 STAR KNOB BOLT M10-1.5 X 20
18-3 P0513X2B018-3 INT RETAINING RING 47MM 67 P0513X2B067 STAR KNOB BOLT M10-1.5 X 53
18-4 P0513X2B018-4 LOWER WHEEL 17" 68 P0513X2B068 THREADED HANDLE M10-1.5
18-5 P0513X2B018-5 URETHANE TIRE, 1-PAIR 69 P0513X2B069 CAM
19 P0513X2B019 MAG SWITCH ASSEMBLY MPE-18 70 P0513X2B070 PILLOW BLOCK
19-1 P0513X2B019-1 MAG SWITCH COVER ASSEMBLY 71 P0513X2B071 HANDLE M12-1.75
19-2 P0513X2B019-2 CONTACTOR SDE MA-18 220V 72 P0513X2B072 LEVER
19-3 P0513X2B019-3 OL RELAY SDE RA-20 8-12A 73 P0513X2B073 HEX NUT M12-1.75
19-5V2 P0513X2B019-5V2 PWR CORD 14G 3W 6-15P V2.02.12 74 P0513X2B074 LEVER HUB
19-6V2 P0513X2B019-6V2 CONTROL CORD 16G 5W V2.05.11 75 P0513X2B075 BUTTON HD CAP SCR M8-1.25 X 20
19-7 P0513X2B019-7 MOTOR CORD 14G 5W 76 P0513X2B076 LOCK WASHER 8MM
19-8 P0513X2B019-8 PHLP HD SCR M5-.8 X 10 78 P0513X2B078 SHAFT COVER
19-9 P0513X2B019-9 RECTIFIER PU-23-2 79 P0513X2B079 SET SCREW M8-1.25 X 20
21 P0513X2B021 WHEEL FLAT WASHER 8MM 80 P0513X2B080 HEX NUT M8-1.25
22 P0513X2B022 CAP SCREW M8-1.25 X 16 81 P0513X2B081 LOWER WHEEL SHAFT
23 P0513X2B023 SAW BLADE 131.5" X 1/2" 6TPI HOOK 82 P0513X2B082 MOTOR 2HP 220V 1-PH W/BRAKE
24 P0513X2B024 LOCK WASHER 8MM 82-2 P0513X2B082-2 MOTOR FAN COVER
25 P0513X2B025 CAP SCREW M8-1.25 X 20 82-3 P0513X2B082-3 MOTOR FAN
28 P0513X2B028 LOWER WHEEL PULLEY 82-4 P0513X2B082-4 CAPACITOR COVER
29 P0513X2B029 HEX NUT 1-14 82-5V2 P0513X2B082-5V2 R CAPACITOR 45M 400V 2 X 2-1/2
30 P0513X2B030 LOCK WASHER 1" 82-6 P0513X2B082-6 MOTOR JUNCTION BOX
31 P0513X2B031 CONTROL PANEL PLATE 82-9 P0513X2B082-9 MAGNETIC BRAKE YZG
32 P0513X2B032 COMPRESSION SPRING 7 X 8 X 90 82-10 P0513X2B082-10 BRAKE SHOE
33 P0513X2B033 ROLL PIN 3 X 16 82-11 P0513X2B082-11 CAP SCREW M6-1 X 12
34 P0513X2B034 ALIGNMENT PLATE 82-12 P0513X2B082-12 LOCK WASHER 6MM
35 P0513X2B035 THRUST BEARING 51201 82-13 P0513X2B082-13 KEY 5 X 5 X 25
36 P0513X2B036 TAP SCREW M4 X 10 82-14 P0513X2B082-14 BALL BEARING 6203ZZ
37 P0513X2B037 TENSION HANDWHEEL 82-15 P0513X2B082-15 BALL BEARING 6205ZZ
38 P0513X2B038 TENSION ADJUSTING ROD 83 P0513X2B083 HEX BOLT M10-1.5 X 25
39 P0513X2B039 FLANGE SCREW M5-.8 X 10 84 P0513X2B084 LOCK WASHER 10MM
40 P0513X2B040 STOP BUTTON 85 P0513X2B085 MOTOR MOUNT BRACKET
