G0513 Series Bandsaws (Mfd. Since 07/18)
-95-
BUY PARTS ONLINE AT GRIZZLY.COM !
Scan QR code to visit our Parts Store.
G0513X2F Main Parts List
REF PART # DESCRIPTION REF PART # DESCRIPTION
2 P0513X2F002 SET SCREW M6-1 X 10 59 P0513X2F059 CAP SCREW M6-1 X 25
3 P0513X2F003 BUSHING 60 P0513X2F060 STAR KNOB
4 P0513X2F004 LIFTING EYE BOLT M10-1.5 61 P0513X2F061 LOCK NUT M6-1
5 P0513X2F005 MACHINE BODY 62 P0513X2F062 STRAIN RELIEF 16MM STRAIGHT LT
7 P0513X2F007 BUSHING 63 P0513X2F063 HEIGHT POINTER
8 P0513X2F008 FLAT WASHER 6MM 64 P0513X2F064 HEX NUT M8-1.25
10 P0513X2F010 HEX NUT M6-1 65 P0513X2F065 HEX BOLT M8-1.25 X 90
11 P0513X2F011 POINTER 66 P0513X2F066 STAR KNOB BOLT M10-1.5 X 20
12 P0513X2F012 STEP SCREW M4-.7 X 5 67 P0513X2F067 STAR KNOB BOLT M10-1.5 X 55
13 P0513X2F013 HINGE SHAFT 68 P0513X2F068 THREADED HANDLE M10-1.5
14 P0513X2F014 ROLL PIN 5 X 36 69 P0513X2F069 CAM
15 P0513X2F015 UPPER WHEEL SHAFT HINGE 70 P0513X2F070 PILLOW BLOCK
16 P0513X2F016 UPPER WHEEL SHAFT 71 P0513X2F071 HANDLE M12-1.75
17 P0513X2F017 UPPER WHEEL ASSEMBLY 72 P0513X2F072 LEVER
17-1 P0513X2F017-1 BUSHING 73 P0513X2F073 HEX NUT M12-1.75
17-2 P0513X2F017-2 BALL BEARING 6204-2RS 74 P0513X2F074 LEVER HUB
17-3 P0513X2F017-3 INT RETAINING RING 47MM 75 P0513X2F075 BUTTON HD CAP SCR M8-125 X 20
17-4 P0513X2F017-4 UPPER WHEEL 17" 76 P0513X2F076 LOCK WASHER 8MM
17-5 P0513X2F017-5 URETHANE TIRE 17" 1-PAIR 78 P0513X2F078 SHAFT COVER
18 P0513X2F018 LOWER WHEEL ASSEMBLY 79 P0513X2F079 SET SCREW M8-1.25 X 20
18-1 P0513X2F018-1 BUSHING 80 P0513X2F080 HEX NUT M8-1.25
18-2 P0513X2F018-2 BALL BEARING 6204-2RS 81 P0513X2F081 LOWER WHEEL SHAFT
18-3 P0513X2F018-3 INT RETAINING RING 47MM 82 P0513X2F082 MOTOR 2HP 110V/220V 1-PH
18-4 P0513X2F018-4 LOWER WHEEL 17" 82-1 P0513X2F082-1 MOTOR FAN COVER
18-5 P0513X2F018-5 URETHANE TIRE, 1-PAIR 82-2 P0513X2F082-2 MOTOR FAN
21 P0513X2F021 WHEEL FLAT WASHER 8MM 82-3 P0513X2F082-3 CAPACITOR COVER
22 P0513X2F022 CAP SCREW M8-1.25 X 16 82-4 P0513X2F082-4 R CAPACITOR 40M 250V 1-3/8 X 2-5/8
23 P0513X2F023 SAW BLADE 131.5" X 1/2" 6TPI HOOK 82-5 P0513X2F082-5 MOTOR JUNCTION BOX
24 P0513X2F024 LOCK WASHER 8MM 82-6 P0513X2F082-6 S CAPACITOR 300M 250V 1-1/2 X 2-3/8
25 P0513X2F025 CAP SCREW M8-1.25 X 20 82-7 P0513X2F082-7 CONTACT PLATE 5/8
28 P0513X2F028 WHEEL PULLEY/BRAKE DRUM 82-8A P0513X2F082-8A CENTRIFUGAL SWITH W/CONT PLATE
29 P0513X2F029 HEX NUT 1-14 82-8 P0513X2F082-8 CENTRIFUGAL SWITCH 5/8-1725
30 P0513X2F030 LOCK WASHER 1" 82-9 P0513X2F082-9 BALL BEARING 6205ZZ
32 P0513X2F032 COMPRESSION SPRING 7 X 8 X 90 82-10 P0513X2F082-10 BALL BEARING 6203ZZ
33 P0513X2F033 ROLL PIN 3 X 16 83 P0513X2F083 HEX BOLT M10-1.5 X 25
34 P0513X2F034 ALIGNMENT PLATE 84 P0513X2F084 LOCK WASHER 10MM
35 P0513X2F035 THRUST BEARING 51201 85 P0513X2F085 MOTOR MOUNT BRACKET
37 P0513X2F037 TENSION HANDWHEEL 86 P0513X2F086 BUTTON HD CAP SCR M8-125 X 20
38 P0513X2F038 TENSION ADJUSTING ROD 87 P0513X2F087 STRAIN RELIEF PLATE 1-HOLE
39 P0513X2F039 FLANGE SCREW M5-.8 X 10 88 P0513X2F088 FLANGE SCREW M5-.8 X 10
43 P0513X2F043 CONTROL PANEL PLATE 89 P0513X2F089 PILLOW BLOCK
44 P0513X2F044 CAP SCREW M8-1.25 X 16 90 P0513X2F090 KEY 5 X 5 X 35
45 P0513X2F045 FENDER WASHER 8MM 91 P0513X2F091 HEX BOLT M8-1.25 X 20 LH
46 P0513X2F046 UPPER WHEEL SLIDING BRACKET 92 P0513X2F092 MOTOR PULLEY TYPE-A 3.5"
47 P0513X2F047 CAP SCREW M8-1.25 X 50 93 P0513X2F093 V-BELT A42
48 P0513X2F048 STEEL BLIND RIVET 3 X 13MM 94 P0513X2F094 CAP SCREW M6-1 X 10
49 P0513X2F049 CAP SCREW M6-1 X 10 95 P0513X2F095 LOWER WHEEL COVER
50 P0513X2F050 CLEAR WINDOW 97 P0513X2F097 FENDER WASHER 8MM
55A P0513X2F055A UPPER WHEEL COVER ASSY 111 P0513X2F111 CAP SCREW M6-1 X 20
55 P0513X2F055 UPPER WHEEL COVER 119 P0513X2F119 FLAT WASHER 4MM
56 P0513X2F056 HEX BOLT M6-1 X 25 188 P0513X2F188 FLANGE SCREW M5-.8 X 10
57 P0513X2F057 FLAT WASHER 6MM 189 P0513X2F189 CORD CLIP 5/16"
58 P0513X2F058 WHEEL BRUSH 190 P0513X2F190 TAP SCREW M4 X 10
