GSK 980MDc - Appendix 11 Explanations for Standard Ladder Function; Address Definition

Appendix
419
Appendix
Appendix 11 Explanations for Standard Ladder Function
11.1 Address Definition
CN61
PLC
address
Symbo Description Note
1 X0.0 TDEC
detect Cutter back to 0 in
position
BT40 pot/turret
2
X0.1 SP External feed hold signal
3
X0.2 TPCH Cylinder pressure test
BT40 pot /turret
4
X0.3 DECX Signal of X-axis deceleration fixed address
5
X0.4 TCOT Tool post counting
BT40 pot/turret
6
X0.5 ESP External emergency stop signal fixed address
7 X0.6 THCH
Toolcase horizontally in position
detection/toolpot back in position
detection
BT40 pot/turret
8 X0.7 TVCH
Toolcase vertically in position
detection/toolpot forward in
position detection
BT40pot/turret
9 X1.0 THSP/ STCK
Stop detection of ATC arm of pot
tool magazine/spindle tool
detection signal in turret tool
magazine
BT40pot/turret
10 X1.1 THGT/ THCK
Catching tool detection of the
ATC arm of pot tool
magazine/the current place dry
detection in turret tool magazine
BT40pot/turret
11 X1.2 THZP
Disc-tools tool changer arm
origin detection
BT40 pot
12
X1.3 DECZ Signal of Z-axis deceleration fixed address
13
X1.4 ST External cycle start signal
14 X1.5 JOGT
External spindle
releasing/clamping tool input
BT40pot/turret
15
X1.6 SAGT Safe door signal
16
X1.7 TRCH Spindle releasing tool detection
BT40 pot/turret
29
X2.0 TGCH
Spindle clamping tool
detection
BT40 pot/turret
30
X2.1 THOV
motor of the ATC arm in pot
magazine overload
BT40 pot
31
X2.2 TTOV Tool changer motor overloaded
BT40pot/turret
32
X2.3 DECY Signal of Y -axis deceleration fixed address
33 X2.4 DEC4
Signal of the 4
th
axis
deceleration
fixed address
34 X2.5 DEC5 Signal of the 5
th
axis fixed address
