GSK980MDc Milling CNC System User Manual
26
I Programming
can be omitted）
G0 X0 Y0； （Move to X0 Y0 at the rapid traverse rate, modal G command G0 valid）
M30；
Example 2
O0002；
G0 X50 Y5；（Move to X50 Y5 at the rapid traverse rate）
G04 X4；（Time delay for 4 seconds）
G04 X5；（Time delay again for 5 seconds，non-modal command G04 should be input again）
M30；
Example 3: (the first operation after the power is turned on)
O0003；
G90 G94 G01 X100 Y100 F500; （G94 feed per minute，feedrate is 500mm/min）
G91 G95 G01 X10 F0.01; （G95 feed per revolution, input the F value again）
G90 G00 X80 Y50；
M30；
3.1.3 Related Definition
The words or characters which are not specially described in this manual are as follows:
Start point: the position before performing the current block;
End point: the position after performing of the current block;
X: the end point absolute coordinate of X axis for G90, the incremental value of X axis against
current point for G91;
Y: the absolute coordinate of Y axis at the end for G90, the incremental value of Y axis against
current point for G91;
Z: the absolute coordinate of Z axis at the end for G90, the incremental value of Z axis against
current point for G91;
F: Cutting feedrate.
3.1.4 Address Definition
Usage of the address in system is as follows:
Address Function Value range
Roundin
g
Punching number of 1 and 3rd side for
rectangle serial punch(G140/G141)
0 ～ 9999 ， Absolute value for
negative
Decimal
part
omitted
4th，5th axis，axis name address
-99999999～99999999×least input
increment
Round-off
A
Width of outer rectangular roughing
milling（G132/G133）in X direction
-9999999～99999999，×least input
increment ， absolute value of
negative number
Round-off
