GSK980MDc Milling CNC System User Manual
28
I Programming
G112,G113: distance from start point to
center point
-99999999～99999999×least input
increment, absolute value of
negative number
Round-off
G114,G115: distance from start point to
circle
-99999999～99999999×least input
increment, absolute value of
negative number
Round-off
G134~G139: width of rectangle in Y
direction
-99999999～99999999×least input
increment, absolute value of
negative number
Round-off
G140,G141: length of 2nd side of
rectangle
-99999999～99999999×least input
increment, absolute value of
negative number
Round-off
Distance from arc start point to
the center point in Z direction
-99999999～99999999×least input
increment
Round-off
G110,G111,G116,G117,G132,G133,G1
34,G135：cutting increment in XY plane
each time
-99999999～99999999×least input
increment, absolute value of
negative number
Round-off
G136~G139: distance from start
point to rectangle side in X axis
direction
-99999999～99999999×least input
increment, absolute value of
negative number
Round-off
K
G50,G51：scale
-99999999～99999999×least input
increment，K must not be 0
Round-off
The length of linear chamfering
-99999999～99999999×least input
increment, absolute value of
negative number
Round-off
Punching number for linear serial
punch (use together with the canned
cycle punch)
-99999999～99999999×least input
increment, absolute value of
negative number
Decimal
part
omitted
Tool life management, tool life value 0~ 999999
Decimal
part
omitted
L
Cycle times of M98 call subprogram
1~9999
Decimal
part
omitted
M miscellaneous function
0~99
Decimal
alarm
M
M code subprogram call
9000~9999
Decimal
alarm
Program number
0~2
31
Decimal
alarm
N
Tool life: tool life unit
(0-time, non-0 -time)
0 or other number
Decimal
alarm
O
Program number
0~9999
