GSK980MDc Milling CNC System User Manual
44
I Programming
Of course, the polar coordinate command mode is cancelled by G15, and then is specified again by
G16 and the new polar position is set.
Axes commands that are not considered as polar coordinate commands
In the polar coordinate mode, the following specified axes are not considered as the polar coordinate
command. Moreover, the axes other than the first and the second axes on the selected plane are not
considered as the polar coordinate command.
G command Function G command Function
G04 Dwell G52 Set the local coordinate system
G53
Select the machine
coordinate system
G92
Set the workpiece coordinate
system
G28,G30
Return to the reference
point
G31 Skip
G65,G66 Call macro program G51.1,G50.1 Programmable mirror image
G51,G50 Scaling G68,G69 Coordinate system rotation
Limitations
z In the polar coordinate mode, specify a radius for circular interpolation or helical cutting (G02, G03)
with R.
z In the polar coordinate mode, no chamfer function can be specified.
z Cylinder interpolation mode cannot be specified in polar coordinate mode.
Cancel the polar coordinate mode
z Specify G15
z Reset
z Program execution finished
Example
Bolt hole circle machining
z Specify angles and radius with absolute commands
