C-viii GTECH Technical Training and Support Services
4 COVER-PAPER (SeeTable C-8, “Assembly-Paper Cover
(Mfg. #28-09955),” on page C-xii
16-2057-01E
TYWRAP- 3 3/8” (MFG. Part # 98-0941) 10-2155-01E
6 MECHANISM ASSEMBLY - LOWER (SeeTable C-9,
“Assembly-Lower Mechanis
m,” on page C-xiv
24-1786-01E
7 RETAINER - SLACKER SPRING 11-4271-01E
8 SCREW #6-20 X 3/8 THD CUT PHD PHPS 10-1366-01
9 TAB-FASTON .187 X .019 (MFG. # 98-03968) 10-1369-01
10 SPRING - SLACKER (LEFT) 17-1144-01E
11 SPRING - SLACKER (RIGHT) 17-1145-01E
12 POWER SUPPLY-3 WIRE CEC COMPLIANT 50-0432-01E
Table C-4. MISC/COMMON
Number Description
GTECH Part
Number
CARTON-BROWN SHIPPING (Part # 90-7579) 10-1369-01
POWER CORD-IEC320 C5 TO C14 (STRAIGHT) 98-10562L
PACK-BOTTOM (Part # 28-09964) 73-0830-02
PACK-TOP (Part # 28-09965) 73-0830-03
# 6 X-18 X 1/4 TAP PHD PHPS (7) MO67883-03
Table C-3. Printer Assembly
Number Description
GTECH Part
Number
