Gtech Accutherm - Assembly-Knife;Slacker (15-3737-01 E)

Spare Parts and Tools
Service Manual for Accutherm Ultra Printer C-xvii
Table C-10. Assembly-Knife/Slacker (15-3737-01E)
Number Description
Mfg. Part
Numbe
r
GTECH Part
Number
1 # 6 X-18 X 1/4 TAP PHD PHPS MO67883-03 10-2144-01E
2 ASSY - JAM SENSOR M280 ULTRA 28-09151L 20-1307-01E
3 ASSY-M280 ULTRA TOF SENSOR 28-08445L 24-1791-01E
4 DRIVE SHAFT (ASSY) 28-09749 15-3738-01E
5 MOLDED FIXED BLADE GTECH (ASSY) 28-06806 15-1462-01
6 BEARING - PLATEN (RETAINER) 28-09827 17-1134-01E
7 BEARING PLATEN (M280) 28-09752 17-1135-01E
8 BEARING - PLATEN (950 SERIES) 95-04963 17-1136-01E
9 BRACKET - KNIFE SPRING 28-09748 17-1137-01E
10 BRACKET LATCH - ARM 28-09771 16-2085-01E
11 BUTTON - PAPER COVER 28-09850 16-2059-01E
12 RING-E .188 DIA 98-1390 10-1370-01
13 GEAR-30 TOOTH 28-09698 13-1025-01E
14 GEAR-30T-DRIVE 28-09701 13-1026-01E
15 GEAR - PLATEN 28-09744 13-1027-01E
16 ASSY-M280 ULTRA STACKER MOTOR 28-09173L 24-1785-01E
17 HUB - LATCH 28-09738 15-3740-01E
18 KNIFE - FRAME 28-09729 11-4273-01E
19 LATCH - ARM 28-09772 12-1035-01E
20 LATCH ARM - ASSY 28-09819 15-3741-01E
21 PLATE SIDE - LEFT (ASSY) 28-09767 15-3743-01E
22 PLATE SIDE - RIGHT (ASSY) 28-09765 15-3744-01E
23 PLATEN 28-09825 15-3745-01E
24 RETAINER -E-RING .25 DIA. 520-9800006 10-2146-01E
25 RETAINER -E-RING .125 DIA. 520-9800002 10-2147-01E
26 RETAINER -E-RING .156 DIA. 520-9800003 10-2148-01E
