Gtech Accutherm - Assembly - MID-Frame (16-2055-01 E)

Spare Parts and Tools
Service Manual for Accutherm Ultra Printer C-xi
Assembly - Mid-Frame (16-2055-01E)
Table C-7. Assembly-Mid-Frame (16-2055-01E)
Number Description
Mfg. Part
Numbe
r
GTECH Part
Number
ASSY-MIDFRAME 28-09950 16-2055-01E
1 LENS - LED 28-09869 13-1040-01E
2 MIDFRAME - PRI NTER 28-09840 Substitute entire
ASSY
16-2055-01E
3 PLUNGER - MIDFRAME 28-09873 17-1151-01E
4 SPRING- PLUNGER 28-09874 17-1150-01E
