Diagnostics
Service Manual for the Accutherm Ultra Printer 5-5
Hard Errors
Hard errors have a similar pattern to Soft errors only they are slower and repeat
every 10 seconds. In general they occur during level 0 diagnostics and are not
recoverable.
NOTE! When the YELLOW and RED LEDs are illuminated at the
same time, the LED will illuminate as
ORANGE/AMBER.
Hard Error State Indicators
Power (Green) Error (Red) Paper (Yellow)
EEPROM read fault 2 Blinks On Off
EEPROM write fault 3 Blinks On Off
Error Vector Taken 4 Blinks On Off
Knife Error 5 Blinks On Off
Flash File system Error 7 Blinks On Off
Flash Read/Write Error 9 Blinks On Off
Dynamic Memory Allocation 10 Blinks On Off
Font system Fault 11 Blinks On Off
Static Memory Allocation 12 Blinks On Off
Communications Fault 14 Blinks On Off
Kernel Fault 15 Blinks On Off
Head Connection Fault 16 Blinks On Off
