Disassembly
Service Manual for the Accutherm Ultra Printer 7-19
Figure 7-19. Slide Stacker Shaft to Right and Remove, then Remove Two Transport Rollers
4. Remove Stacker Guide from Frame being careful not to bend the
frame tabs.
Reassemble reversing the above steps. Ens
ure the Compensation Bearings, the
shaft and rollers move freely in the frame.
