BASIC OPERATION
45
CH1/CH2 Tracking Parallel Mode
Output rating Rating 0 - 32V/0 - 6A
Operation
1. Press F4 or F5 button for operating the
corresponding Parallel to enter the tracking
parallel function. Yellow PAR will be shown on
the status area.
2. Press CH1 button to proceed to CH1/CH2
voltage/current setting.
4. For setting operation of parameter, refer to page
37.
Output
The button ON/OFF of CH1/CH2 is individually
available, while All ON/OFF button is available
for all channels.
CAUTION: under tracking parallel mode, CH1 is master, whilst
CH2 is slave. Thus, output voltage/current setting is Not available for
CH2.
Load
+ -
