BASIC OPERATION
55
Points
Select the required points. Range: 10-
2047
Inverted
Invert the selected waveform
Parameter
Setting
Object
Press the F1 (Object) button to select
Voltage /Current
in turn. Simply stop at the
parameter which is in need of
setting.
Type
Afer pressing the F2 (Type) button,
select the button corresponding to
the applicable waveform. Up to 8
default waveforms are available for
selection.
Max
Value
Press the F3 (Max Value) button. The
setting on LCD will be activated and
appears in red front color
. Use number pad to set
the parameters directly and then
press the F1 (V/A) or the F2
(mV/mA) button to confirm; or use
arrow keys along with scroll wheel
to complete the setting.
Min
Value
Press the F4 (Min Value) button. The
setting on LCD will be activated and
appears in red front color. Use
number pad to set the parameters
directly and then press the F1 (V/A)
or the F2 (mV/mA) button to
confirm; or use arrow keys along
with scroll wheel to complete the
setting.
