H3C S3600 Series Installation Manual

Installation Manual
H3C S3600 Series Ethernet Switches Chapter 1 Product Overview
1-6
LED Mark Status Indication
POST
running
The PWR LED
flashes green
Displays the POST test ID (in the
range of 1 to 9).
The PWR LED
flashes yellow
POST
failed
The PWR LED
is solid red
Flashes the POST test ID of the
failed test.
Software
downloa
ding
The PWR LED
flashes green
A bar rotates clockwise around
the LED.
Fan
failed
The PWR LED
is solid red
Displays “F”.
7-segm
ent
digital
LED
Unit
Unit ID Button released
Displays the unit ID in the fabric;
and displays “1” if there is only
one unit.
III. Attributes of the 10Base-T/100Base-TX Ethernet ports
Table 1-3 Attributes of the 10Base-T/100Base-TX Ethernet Ports on the S3600-28P-SI
Attribute Description
Connector RJ-45
Number of ports 24
Rate
z 10 Mbps, half duplex/full duplex
z 100 Mbps, half-duplex/full duplex
z MDI/MDI-X auto-sensing
Standard IEEE 802.3u
Transmission distance
over the selected medium
100 m (328.08 ft) over the category-5 unshielded
twisted pair (UTP) cable
IV. Console port
The S3600-28P-SI provides one EIA/TIA-232 compliant Console port for local or
remote configuration.
Table 1-4 lists the attributes of the Console port.
Table 1-4 Console port attributes
Attribute Description
Connector RJ-45
Standard Asynchronous EIA/TIA-232
Baud rate 9600 bps (default)
